Deep Engraving Metal Fiber Enclosed Laser Marking Machine

Key Features: ✔ Fully Enclosed Safety Design – Protects the operator from laser exposure and dust.✔ Deep Metal Engraving Capability – Achieves high-con

  • Color: Default Color
  • Size: Default Size
  • Origin: China
  • Usage: Default Usage
  • Type: Default Type
  • Efficiency: 99.9% Type
New
  • Deep Engraving Metal Fiber Enclosed Laser Marking Machine
  • Deep Engraving Metal Fiber Enclosed Laser Marking Machine

Description:

Key Features:

Fully Enclosed Safety Design – Protects the operator from laser exposure and dust.
Deep Metal Engraving Capability – Achieves high-contrast, permanent markings on various metals.
High-Speed Galvo Scanner – Ensures fast, precise marking with smooth edges.
Fiber Laser Technology – Long lifespan of up to 100,000 hours with minimal maintenance.
Available in Multiple Power Options – 30W, 50W, 100W for different engraving depths.
EZCAD Software Compatibility – Supports multiple file formats for easy design import.
High Positioning Accuracy – Ensures sharp and detailed engraving results.
No Consumables Required – Low operating costs with energy-efficient performance.
Supports Rotatory Engraving – Optional rotary attachment for engraving cylindrical objects.


Specifications:

  • Laser Power: 30W / 50W / 100W (Fiber Laser)

  • Marking Area: Standard 110x110mm (Optional: 150x150mm, 200x200mm)

  • Marking Speed: Up to 7000mm/s

  • Engraving Depth: 0.01mm - 1.0mm (varies by power and material)

  • Wavelength: 1064nm

  • Cooling System: Air Cooling

  • Positioning Accuracy: ±0.01mm

  • Software: EZCAD (supports PLT, DXF, BMP, JPG, AI, etc.)

  • Compatible Operating System: Windows XP/7/8/10

  • Laser Lifespan: 100,000+ hours

  • Power Supply: 110V/220V, 50/60Hz

  • Weight: Approx. 50-80kg (varies by model)


Applications:



Deep Metal Engraving (Stainless Steel, Aluminum, Brass, Copper, Titanium)
Industrial Tool & Machine Part Marking
Aerospace & Automotive Component Engraving
Jewelry & Luxury Metal Engraving
Electrical & Electronic Component Marking
Barcode, QR Code, and Serial Number Marking
Rotary Engraving for Cylindrical Objects
